This recovery ventilator is an easy and effective solution for rooms and smaller areas, and provides innvoative ventilation for fresh air intake and stale air exhaust.
Features
- Fresh air supply
- Heating cost savings during winter
- Indoor humidity control
- One Breathe-Right HRV can ventilate upt o 343 sq. ft.
- Units can operate independently or can be wired for master-slave operation
- Air filtration
- Anti-bacterial air treatment
- Polluted air extract
- 5 Year Warranty
Benefits
Plug-&-Play Installation
- No special skills required
- No balancing needed
- Through the wall installation
- Compact unit design
Multifunctional Wireless Remote Control
- Almost no maintenance required
- Washable filter and core
- MERV6 air purification
- Antibacterial treatment of
Aluminum Outer Hood
- Modern design that fits any interior and exterior
- 100% corrosion proof
EC Motor
- Efficacy 5.7 CFM/W – twice as high as the Energy Star requirement
- Whisper quiet operation, as low as 0.1 SONES
Patent Pending on Ceramic ERV Core
External rotor motor on ball bearing with thermal protection ensures long life of the fans.
Operation of Breathe-Right
The ventilator is designed for both extract and supply ventilation with energy recovery function.
CYCLE I: While warm, stale air is extracted from a room it passes through the ceramic energy core where the heat and moisture is being accumulated. After the ceramic core heats up, the ventilator automatically switches to supply mode.
CYCLE II: As the clean, fresh air from outside passes through the ceramic energy core, it absorbs moisture and it warms up due to the accumulated heat. As temperature of the accumulated drops down, the fan switches to extract mode and the cycle is renewed. The ventilator changes its operation mode for supply or extract ventilation every 70 seconds.
