Custom Aluminum Swing Gates —
Built for Rural, Estate & Equine Properties
The most widely used driveway gate style — available in single and double configurations, with LiftMaster automation and our SystemPost™ pre-wired post for a fast, clean installation.
What Is a Swing Gate?
A swing gate opens by rotating inward or outward on hinges mounted to a post or pillar. It is the most common driveway gate style for rural properties, estates, and equine facilities — and for good reason. Swing gates are mechanically simple, visually strong, and available in a wide range of sizes and configurations to suit almost any entrance.
System Fencing manufactures custom aluminum swing gates in our Ontario facility. Gate can ship as a complete package with the SystemPost™ pre-wired post, internal post or 6×6 posts— so your local electrician connects to a finished unit, not a pile of loose wire runs.
When a Swing Gate Is the Right Choice
Swing gates work best when:
- There is adequate clearance for the gate to open inward or outward without obstruction
- The driveway grade across the opening is relatively level (steep upward slopes toward the gate can cause ground clearance issues)
- The entrance has stone, timber, or precast pillars that suit a hinge-mount installation
- The property has an existing fence or wall the gate needs to match in style
- The owner wants the most traditional, visually substantial entrance appearance
A swing gate is generally not the right choice when:
- The driveway slopes significantly upward immediately past the opening (the gate arc will contact the grade)
- The entrance is on a tight urban lot with limited swing clearance in front of or behind the gate
- The Site has driveway opening of over 23ft this is where a sliding gate would be more benefical.
Swing Gate Configurations
Many configurations are available, call, text or email for the best options.
Single Swing
Double Swing
Best for
Single-lane driveways, pedestrian+vehicle access
Two-lane or wide estate entrances, symmetrical pillars
Typical width
Up to 12 ft
14 – 24 ft (7–24 ft per leaf)
Automation
LiftMaster LA500 / Nice Toona 5 High Speed
LiftMaster CSW / Nice toona 5 High Speed operator
SystemPost™
Optional
Optional
Solar compatible
Yes — with correct operator selection
Yes — with correct operator selection
Custom styles
Flat top, curve top, board & rail
Flat top, curve top, board & rail, matched pair
The SystemPost™ — Why It Matters for Swing Gates
Optional automated swing gate package from System Fencing includes the SystemPost™ — a gate post with all wiring integrated at the factory before it leaves our facility. Wire, electrical connections, and operator wiring are all pre-installed inside the post. Your electrician arrives to a finished connection point, not a raw column.
For swing gates specifically, this matters because the operator is typically mounted to the post or inside a pillar, and field-wiring through a finished stone or precast column is difficult, messy, and expensive. The SystemPost™ eliminates all of that.
- All gate wiring pre-installed before shipping
- Compatible with LiftMaster, Nice, and AES intercom systems
- Designed for a clean hookup by any licensed electrical contractor
- Available on single and double swing automated packages
HOW IT WORKS
Our Swing Gate Process
Share your opening width, pillar or post setup, driveway grade, power availability, and a few site photos from the approach and inside.
Single or double, flat or curve top, operator selection, and whether solar or conventional power suits your site. We also confirm whether swing is the right style for your grade.
Your aluminum swing gate and pre-wired SystemPost™ are fabricated in our Ontario facility to your exact specification.
Supply-only delivery anywhere in Ontario and the US, or full supply and install. Your electrician connects to the finished SystemPost™ — fast, clean, no surprises.
Swing Gate Automation
System Fencing is authorized to supply and install LiftMaster, Nice, and AES intercom systems on all swing gate packages.
LiftMaster
Nice
Solar
Best for
High-reliability residential & light commercial
Estate and premium residential
Remote entrances without grid power
Gate weight rating
Up to 500 lb per leaf (LA500)
Up to 600 lb per leaf (Toona 5)
Varies by model — confirm with us
Access options
Remote, keypad, app (myQ)
Remote, keypad, GSM
Remote, keypad
Intercom compatible
AES, Oypn
AES, Oypn
No intercom for solar applications
Warranty
2 yr manufacturer
2 yr manufacturer
Operator-dependent
Best for
LiftMaster: High-reliability residential & light commercial
Nice: Estate and premium residential
Solar: Remote entrances without grid power
Gate weight rating
LiftMaster: Up to 500 lb per leaf (LA500)
Nice: Up to 600 lb per leaf (Toona 5)
Solar: Varies by model — confirm with us
Access options
LiftMaster: Remote, keypad, app (myQ)
Nice: Remote, keypad, GSM
Solar: Remote, keypad
Intercom compatible
LiftMaster: AES, Oypn
Nice: AES, Oypn
Solar: AES (low-power models)
Warranty
LiftMaster: 3 yr manufacturer
Nice: 2 yr manufacturer
Solar: Operator-dependent
Common questions
Swing Gate Questions
It depends on the direction and degree of the slope. If the driveway slopes upward immediately past the opening, the arc of the gate may contact the ground as it opens. We assess this from your site photos and can recommend whether swing or sliding is the better fit for your specific grade.
We can fabricate double swing gates up to approximately 30 ft total width — 15 ft per leaf. For very wide openings, we will confirm the appropriate operator and hinge specification based on gate weight.
The SystemPost™ is our pre-wired gate post — all conduit and wiring is integrated at our facility before shipping. It is included on all automated swing gate packages. It makes installation faster and cleaner for your local electrician, and ensures consistent, code-friendly wiring every time.
Yes. With the right operator selection and a realistic assessment of your daily cycle count, solar-powered swing gate automation is reliable and effective. We will help confirm suitability during the quote process.
Both. We ship custom aluminum swing gates and SystemPost™ packages anywhere in Ontario and the US for supply-only customers. We also offer full installation in our service area.
Ready to Talk Swing Gates?
Tell us your opening width, pillar setup, and power availability — and our team will come back with the right configuration, operator recommendation, and a tailored quote including the SystemPost™.
